Cinetto PS66 Sliding System for Retractable Doors

The Cinetto PS66 Sliding System for Retractable Doors is an innovative hardware solution that creates clean, concealed storage with smooth retractable door operation. Available for both glass and wooden doors, the PS66 eliminates the need for upper and lower floor rails, delivering a minimalist appearance that is perfect for contemporary interiors, wardrobes and bespoke furniture.

Cinetto PS66 Retractable Door System

The PS66 allows doors to slide effortlessly into a concealed compartment, keeping the front of the cabinet or storage area completely unobstructed. As a result, it creates a sleek and modern finish while maximising access to the space behind the doors.

Furthermore, the integrated Softspace soft closing system ensures controlled and quiet operation, improving both comfort and everyday usability.

Flexible Installation for Glass and Wood Doors

Designed with versatility in mind, the Cinetto PS66 is available for 8 mm glass doors or 25–40 mm wooden doors, with a maximum door weight of 50 kg. In addition, the system supports door widths from 600 mm to 1000 mm and installation heights between 2100 mm and 3000 mm.

The mechanism also features convenient ±3 mm height adjustment, allowing quick and accurate alignment during installation. Moreover, the minimum clearance from the floor and ceiling is only 12 mm, creating an elegant built-in appearance. The space above the retractable door module can even be reduced to zero, providing greater design freedom.

Optional Automatic Opening System

For added convenience, the PS66 can be upgraded with an optional electronic opening and closing system. Better still, this accessory can be retrofitted at any time, allowing furniture to be upgraded without replacing the existing mechanism.

Features and Benefits

• Retractable sliding door system for glass and wooden doors
• No upper or lower floor rails required
• Integrated Softspace soft closing mechanism
• Optional electronic opening and closing system
• Suitable for doors up to 50 kg
• Glass door thickness: 8 mm
• Wooden door thickness: 25–40 mm
• Door widths from 600 mm to 1000 mm
• System heights from 2100 mm to 3000 mm
• Convenient ±3 mm height adjustment
• Minimum floor and ceiling gap of only 12 mm

Premium Retractable Door Hardware

Whether you are creating a luxury wardrobe, hidden storage area or bespoke furniture project, the Cinetto PS66 Sliding System delivers exceptional functionality with a minimalist design. Consequently, it is an excellent choice for designers, cabinet makers and furniture manufacturers looking for premium retractable door hardware that combines smooth operation, flexible installation and modern aesthetics.

Additional accessories:

• B-moved – Electric system for opening and closing the doors
