Cinetto PS48 System for Wardrobes with Overlapping Sliding Doors
£1.00–£136.61 ex. VAT
£1.20–£163.93 incl. VAT
- Description
- Additional information
Description
Cinetto PS48 Overlapping Sliding Door System
The Cinetto PS48 is a premium overlapping sliding door system designed specifically for wardrobes and bespoke furniture applications. Engineered for smooth operation and high performance, the system supports door panels weighing up to 80 kg while maintaining a clean and elegant appearance.
Featuring concealed soft-close technology, precision bearing rollers and easy front adjustment, the PS48 offers a reliable solution for modern wardrobes and storage systems.
Designed for Overlapping Sliding Doors
The Cinetto PS48 allows doors to overlap smoothly, maximising access to wardrobe interiors while maintaining a compact footprint. As a result, it is ideal for fitted wardrobes, walk-in dressing rooms and bespoke storage furniture where space efficiency is essential.
Furthermore, the system accommodates a wide range of door materials and thicknesses, providing flexibility for furniture manufacturers and joiners.
Smooth and Quiet Operation
High-quality upper and lower rollers with integrated bearings ensure effortless door movement. In addition, the patented wheel system allows doors to be fastened quickly while helping to prevent accidental self-opening.
For enhanced user comfort, the optional Softspace soft-close mechanism slows the door before it reaches its final position, delivering a smooth and silent closing action.
Concealed Soft-Close Technology
Unlike many conventional systems, the Softspace soft-close mechanism is mounted inside the upper rail. Consequently, the soft-close hardware remains hidden from view, preserving the clean appearance of the wardrobe.
This discreet design makes the Cinetto PS48 particularly suitable for premium furniture and contemporary interiors.
Key Features
Cinetto PS48 Sliding Door System
- Overlapping sliding door system for wardrobes
- Maximum door weight: 80 kg per panel
- Suitable for door thicknesses from 18 mm to 53 mm
- Upper and lower bearing rollers for smooth operation
- Front door adjustment for easier installation
- Concealed Softspace soft-close system
- Patented wheel system prevents accidental opening
- Robust upper rail with anti-buckling design
- Ideal for bespoke furniture and fitted wardrobes
Easy Installation and Adjustment
The system has been designed to simplify installation and fine-tuning. Door adjustment can be performed from the front, allowing installers to achieve precise alignment quickly and efficiently.
In addition, the adjustment range of ±3 mm helps compensate for minor installation variations and ensures smooth operation.
Technical Specifications
- Maximum Door Weight: 80 kg per door
- Door Thickness: 18–53 mm
- Minimum Door Width for Soft-Close: 400 mm
- Door Adjustment: ±3 mm
- Minimum Bottom Clearance: 25 mm (17 mm available on request)
- Minimum Top Clearance: 40 mm
- Roller Type: Bearing-supported upper and lower rollers
- Soft-Close: Concealed Softspace system
Applications
The Cinetto PS48 is ideal for:
- Sliding wardrobes
- Walk-in wardrobes
- Bedroom furniture
- Bespoke storage solutions
- Fitted furniture
- Residential interiors
- Commercial storage systems
Why Choose the Cinetto PS48?
The Cinetto PS48 combines smooth sliding performance, concealed soft-close technology and easy installation in a single premium system. Its high load capacity, overlapping door design and discreet hardware make it an excellent choice for modern wardrobe projects where aesthetics and functionality are equally important.
Additional accessories:
Additional information
| PARTS | Reinforced upper rail; L mm 1523, Reinforced upper rail; L mm 3020, Reinforced upper rail; L mm 6100, Bottom rail; L mm 1523, Bottom rail; L mm 3020, Bottom rail; L mm 6100, Set of wheels for inside panel, Set of wheels for external panel when inside panel is 18 mm thick, Set of wheels for external panel when inside panel is 23 mm thick, Set of wheels for external panel when inside panel is 28 mm thick, Set of wheels for external panel when inside panel is 33 mm thick, SoftSpace® soft-close system for opening and closing; 15 kg, SoftSpace® soft-close system for opening and closing; 30 kg, SoftSpace® soft-close system for opening and closing; 50 kg, SoftSpace® soft-close system for opening and closing; 80 kg, Right-side soft brake promoter is attached to the brackets, Left-side soft brake promoter is attached to the brackets, End position brake when mounting embossed handle (for the protection of the handle; the door can not pass), End position brake with adjustable handle (in set elements for stopping one doors to two sides), End position brake installing to bottom rail, SoftSpace® soft-close system for central door; 30 kg, SoftSpace® soft-close system for central door; 50 kg, Upper rail fixing element; black colour |
|---|
