J95 Heavy-Duty Soft-Close Concealed Hinge

The J95 Heavy-Duty Concealed Hinge is a high-performance cabinet hinge engineered for larger and heavier cabinet doors that demand superior strength, reliability, and smooth operation. Featuring a 95° opening angle and impressive load capacities of up to 40kg using three hinges, the J95 is ideal for oversized cabinet doors, pantry units, wardrobes, utility cupboards, and commercial furniture applications.

Designed for durability and precision, the J95 incorporates a convenient clip-on installation system for quick fitting and removal, while its 3-way adjustment capability allows accurate door alignment after installation. Installers can easily fine-tune depth, height, and overlay positioning to achieve a perfect fit and professional finish.

With an overlay range of 20–25mm, the J95 offers flexibility across a wide variety of cabinet designs. Its heavy-duty construction makes it particularly well suited for large cabinet doors where standard concealed hinges may not provide sufficient support.

Combining strength, adjustability, and easy installation, the J95 Heavy-Duty Concealed Hinge is an excellent solution for premium residential, commercial, and bespoke furniture projects.

Key Features

• Heavy-duty concealed cabinet hinge
• 95° opening angle
• Suitable for larger and heavier cabinet doors
• Overlay range of 20–25mm
• Clip-on installation system for easy fitting and removal
• 3-way adjustment for precise door alignment
• High load-bearing capacity
• Smooth and reliable operation
• Ideal for pantry cabinets, wardrobes, utility cupboards, and commercial furniture
• Durable construction for long-term performance

Technical Specifications

• Product: J95 Heavy-Duty Concealed Hinge
• Opening Angle: 95°
• Overlay Range: 20–25mm
• Installation Type: Clip-on concealed hinge
• Adjustment:
  • Depth: +1.5mm / -2.5mm
  • Vertical: ±3mm
  • Overlay (Horizontal): 0mm / -4mm
• Load Capacity:
  • 25kg per door using 2 hinges
  • 40kg per door using 3 hinges
• Maximum Door Width:
  • 800mm using 2 hinges
  • 900mm using 3 hinges

Applications

The J95 Heavy-Duty Concealed Hinge is ideal for cabinet makers, furniture manufacturers, kitchen installers, and joinery professionals requiring a robust hinge solution for larger cabinet doors. Its exceptional load capacity, clip-on installation, and precision adjustment make it perfect for heavy-duty cabinetry, oversized storage units, wardrobes, and commercial furniture projects.
