Hawa Junior 100 Z Sliding Interior Pocket Door System
£22.45–£456.60 ex. VAT
£26.94–£547.92 incl. VAT
- Description
- Additional information
Description
Fitting for top-running wooden doors up to 100 kg (220 lbs.), with surface mounted running track. Optionally with soft and self closing mechanism. Wall or ceiling mounting.
Product-Highlights
Accessible opening and soft and self closing at both sides from door widths of 800 mm (2′ 7 1/2”)
Running tracks for wall and ceiling mounting with integrated clip-on system
Performance guarantee: 15 years for private use and 7 years for commercial use on incomparably low opening forces of max. 22 N
Technical guidelines
Max. 100 kg (220 lbs.)
Max. 4000 mm (13′ 1 15/32”)
Max. 3000 mm (9′ 10 1/8”)
35–80 mm (1 3/8” to 3 5/32”)Design / Integration
Wall mounting
Ceiling mounting
Top-runningAdditional information
| PART | Hawa Junior 100 Z / Z Pocket, with 2 SoftStop, for 1 door, Hawa Junior 100 Z / Z Pocket, with 1 soft close SoftMove 100 and 1 SoftStop, for 1 door, Hawa Junior 100 Z / Z Pocket with 2 soft close SoftMove 100, for 1 door, Soft closing mechanism SoftMove 80, SoftStop Hawa Junior 80/100, with adjustable retention spring, Stopper Hawa Junior 80/100, with adjustable retention spring, Guide track, for groove mounting, plastic, 1,300mm (4' 3 3/16''), Running track, aluminum, anodized, pre-drilled (2,000mm), Running track, aluminum, anodized, pre-drilled (2,500mm), Running track, aluminum, anodized, pre-drilled (3,000mm) |
|---|
